- 1. The standard specifications for the thickness of PE thread shall be as shown in the table below.
- 2. This standard applies to 100% PE yarn and is the total denier including coatings and pigments.
- 3. The standard thickness of PE thread is expressed in denier (d), with 1 No. = 200d.
- 4. The permissible range for PE thread is such that the upper and lower denier limits do not exceed the standard values for the preceding and succeeding sizes.
-
5. d (denier) represents the mass per 9000 m of length, expressed in grams.
(200d = 200g)
| Number pattern | 0.1 | 0.15 | 0.2 | 0.25 | 0.3 | 0.35 | 0.4 | 0.5 | 0.6 | 0.7 | 0.8 | 1 | 1.2 | 1.5 |
| Standard value (d) | 20 | 30 | 40 | 50 | 60 | 70 | 80 | 100 | 120 | 140 | 160 | 200 | 240 | 300 |
| Number pattern | 1.7 | 2 | 2.5 | 3 | 4 | 5 | 6 | 8 | 10 | 12 | 15 | 20 | twenty five | 30 |
| Standard value (d) | 340 | 400 | 500 | 600 | 800 | 1000 | 1200 | 1600 | 2000 | 2400 | 3000 | 4000 | 5000 | 6000 |
