BREAK YOUR RECORD - Seize and catch your dreams -
"Someday, catch that fish." SALTIGA was born to make anglers' dreams come true. It inherits the strongest genes of DAIWA offshore and continues to evolve with the latest technology.
The premise is to confront unknown large fish. It continues to challenge the limits of tackle, pursuing strength in every area, ease of use, and superior performance. Saltiga is expected to be a tackle that will surely bring you closer to your dream fish. Continuing to fulfill its purpose in existence means that anglers' dreams will come true. Its reliable performance supports the dreams of anglers all over the world.
Daiwa
2025 Saltiga 14000-XH
2025 Saltiga 14000-XH
Harga biasa
MYR3,604.00
Harga biasa
MYR4,240.00
Harga jualan
MYR3,604.00
Harga seunit
per
Taxes included.
Penghantaran dikira semasa pembayaran.
kehabisan stok
Tidak dapat memuatkan ketersediaan pengambilan
| item | Standard weight (g) | Winding length (cm/1 turn of handle) | Gear Ratio | Standard winding amount of PE (No.-m) | Handle arm length (mm) | Bearings (ball/roller) | Maximum drag force (kg) | Spool dimensions (diameter mm) | Handle knob replacement size | Handle knob specifications | Body Material | Number of BBs |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 25 SALTIGA 14000-XH | 690 | 133 | 6.2 | 5-340_6-300 | 85 | 14(14/1) | twenty five | 69 | (L) | HG Egg | AL | 14 |
We transform anglers' passion, smiles, and dreams into the strength of our reels.
How do we make a strong reel that anglers can trust?
A reel with high rigidity that can reliably and safely catch unknown targets in a rare opportunity. A reel with high durability that
can continue to perform as it should for a long time even in harsh natural environments.
How do we achieve something that exceeds the expectations of anglers?
The answer we came to when asking ourselves this question was to tear up all the previous drawings. It cannot be an improvement. It is to start from scratch and draw a line from scratch.
Let go of the past and move forward. Each and every member of the development team accepts the expectations of anglers.
2025 - SALTIGA has been reborn.
The core technology is the power drive design. The design concept of the next generation large spinning reel pursues high reliability to safely deal with large fish all over the world. New technology to fulfill the mission imposed on SALTIGA. In a sense, it is the identity of SALTIGA.
This Power Drive Design consists of two technology units: the body unit [Power Drive Engine] and the rotor unit [Power Drive Rotor]. The
[Power Drive Engine] is made up of two technologies: the large-diameter [Oversized Power Digigear] and the [Roller Power Oscillation] that uses a ball bearing system. These are housed in the large-sized "Full Metal (AL) Monocoque Body" that is extremely strong, making it light from the initial movement and providing a more efficient and powerful winding force.
The front unit is made up of the metal (AL) [Power Drive Rotor], which is based on the [Power Drive Engine]. With a rational spherical shape, it achieves further rigidity while maintaining low inertia. The synergistic effect of the [Crank Power Bail] and [Tough Line Roller System] installed in this rotor enables accurate line delivery and a smooth transition to winding operation.
While reviewing the fundamental design concept of the reel, the drag mechanism was also completely redesigned. Up to the 14000 model, ATD Tough is used, which is made up of a total of 14 washers made of carbon and metal, while the 18000 model and above are equipped with a new drag mechanism called DRD. This is a completely new mechanism with eight metal rollers on one plate, which suppresses the decrease in drag force due to frictional heat. Even in big games where you are forced to fight for a long time, it maintains a smooth start. The
long-distance casting performance has also been improved. Even under bad conditions, you want to deliver the lure as far as possible. In order to meet that expectation, the conventional LC-ABS was redesigned and the LC-ABS SW was newly developed, which has a two-stage taper shape on the upper side of the spool thread winding part toward the spool ring. This reduces the frictional resistance of the line and supports another stretch in the latter half of the cast.
In the field of big games, there is an extremely high risk of salty water entering due to wave overflow and sea breezes. Therefore, Mag Shield is implemented in three places on the rotating part of the line roller part, pinion part, and handle shaft part. It is the only large spinning reel that is completely waterproof.
The lineup includes the existing 8000, 10000, 14000, 18000, and 20000 models, and a new 25000 model has been developed. The line capacity, power, and winding speed required to catch super-large fish, such as large bluefin tuna, have been pursued to meet the high expectations of top anglers who lead the big game scene.
So that you can face the oceans of the world head-on without hesitation. So
that you can continue to use it as your best partner forever.
So that as many people as possible can catch record fish.
Transform the passion, smiles, and dreams of anglers into the strength of the reel.
SALTIGA's new challenge begins here.
A reel with high rigidity that can reliably and safely catch unknown targets in a rare opportunity. A reel with high durability that
can continue to perform as it should for a long time even in harsh natural environments.
How do we achieve something that exceeds the expectations of anglers?
The answer we came to when asking ourselves this question was to tear up all the previous drawings. It cannot be an improvement. It is to start from scratch and draw a line from scratch.
Let go of the past and move forward. Each and every member of the development team accepts the expectations of anglers.
2025 - SALTIGA has been reborn.
The core technology is the power drive design. The design concept of the next generation large spinning reel pursues high reliability to safely deal with large fish all over the world. New technology to fulfill the mission imposed on SALTIGA. In a sense, it is the identity of SALTIGA.
This Power Drive Design consists of two technology units: the body unit [Power Drive Engine] and the rotor unit [Power Drive Rotor]. The
[Power Drive Engine] is made up of two technologies: the large-diameter [Oversized Power Digigear] and the [Roller Power Oscillation] that uses a ball bearing system. These are housed in the large-sized "Full Metal (AL) Monocoque Body" that is extremely strong, making it light from the initial movement and providing a more efficient and powerful winding force.
The front unit is made up of the metal (AL) [Power Drive Rotor], which is based on the [Power Drive Engine]. With a rational spherical shape, it achieves further rigidity while maintaining low inertia. The synergistic effect of the [Crank Power Bail] and [Tough Line Roller System] installed in this rotor enables accurate line delivery and a smooth transition to winding operation.
While reviewing the fundamental design concept of the reel, the drag mechanism was also completely redesigned. Up to the 14000 model, ATD Tough is used, which is made up of a total of 14 washers made of carbon and metal, while the 18000 model and above are equipped with a new drag mechanism called DRD. This is a completely new mechanism with eight metal rollers on one plate, which suppresses the decrease in drag force due to frictional heat. Even in big games where you are forced to fight for a long time, it maintains a smooth start. The
long-distance casting performance has also been improved. Even under bad conditions, you want to deliver the lure as far as possible. In order to meet that expectation, the conventional LC-ABS was redesigned and the LC-ABS SW was newly developed, which has a two-stage taper shape on the upper side of the spool thread winding part toward the spool ring. This reduces the frictional resistance of the line and supports another stretch in the latter half of the cast.
In the field of big games, there is an extremely high risk of salty water entering due to wave overflow and sea breezes. Therefore, Mag Shield is implemented in three places on the rotating part of the line roller part, pinion part, and handle shaft part. It is the only large spinning reel that is completely waterproof.
The lineup includes the existing 8000, 10000, 14000, 18000, and 20000 models, and a new 25000 model has been developed. The line capacity, power, and winding speed required to catch super-large fish, such as large bluefin tuna, have been pursued to meet the high expectations of top anglers who lead the big game scene.
So that you can face the oceans of the world head-on without hesitation. So
that you can continue to use it as your best partner forever.
So that as many people as possible can catch record fish.
Transform the passion, smiles, and dreams of anglers into the strength of the reel.
SALTIGA's new challenge begins here.
Daiwa Technology
MONOCOQUE BODY
Strong and durable technology, monocoque body. Conventional spinning reels generally support both ends of the drive gear with the body and body cover, and secure them with several screws. In order to further improve precision and rigidity, the monocoque body eliminates the body cover and secures the gear by screwing a high-precision plate directly into the body. This improves the support precision of the gear, and also improves rigidity and airtightness. Furthermore, by utilizing the space previously taken up by the screw, we have succeeded in expanding the size of the drive gear to its maximum. The monocoque body means MONO (one) - COQUE (shell). The completely new shape, which symbolizes the strength of a single shell, breaks the conventional wisdom of reel structure.
It uses a full metal (aluminum) monocoque body. The maximum diameter Tough Digigear is enclosed in a highly rigid, lightweight, compact housing.
POWERDRIVE DESIGN
The Power Drive Design is a design concept for next-generation large spinning reels that pursues high reliability so that you can safely compete with large fish all over the world.
This Power Drive Design is composed of two technology units: the body unit [Power Drive Engine] that realizes a powerful winding force with high efficiency, and the rotor unit [Power Drive Rotor] that realizes both high rigidity and low inertia with a rational spherical shape.
The body unit [Power Drive Engine] is composed of two technologies, [Oversized Power Digigear] and [Roller Power Oscillation].
[Oversized Power Digigear] has a large diameter and thick wall, and an optimized tooth surface shape, which greatly improves the gear drive efficiency.
[Roller Power Oscillation] adopts a ball bearing system for the oscillation mechanism, which greatly reduces friction resistance, improves initial response, and realizes light winding.
Meanwhile, the front unit is composed of the [Power Drive Rotor] equipped with two technologies, [Crank Power Bail] and [Tough Line Roller System].
The Crank Power Veil strengthens the opening and closing force of the veil, and the crank shape ensures reliable line feeding to the line roller.
The Tough Line Roller System improves durability and trouble-free performance by reviewing the support structure and shape of the line roller.
The synergistic effect of these technologies achieves high levels of rigidity, power, and durability in casting and jigging games targeting large fish. The "strength" to catch is available to all anglers who love big games.
This Power Drive Design is composed of two technology units: the body unit [Power Drive Engine] that realizes a powerful winding force with high efficiency, and the rotor unit [Power Drive Rotor] that realizes both high rigidity and low inertia with a rational spherical shape.
The body unit [Power Drive Engine] is composed of two technologies, [Oversized Power Digigear] and [Roller Power Oscillation].
[Oversized Power Digigear] has a large diameter and thick wall, and an optimized tooth surface shape, which greatly improves the gear drive efficiency.
[Roller Power Oscillation] adopts a ball bearing system for the oscillation mechanism, which greatly reduces friction resistance, improves initial response, and realizes light winding.
Meanwhile, the front unit is composed of the [Power Drive Rotor] equipped with two technologies, [Crank Power Bail] and [Tough Line Roller System].
The Crank Power Veil strengthens the opening and closing force of the veil, and the crank shape ensures reliable line feeding to the line roller.
The Tough Line Roller System improves durability and trouble-free performance by reviewing the support structure and shape of the line roller.
The synergistic effect of these technologies achieves high levels of rigidity, power, and durability in casting and jigging games targeting large fish. The "strength" to catch is available to all anglers who love big games.
*The 25 SALTIGA is fully equipped with POWERDRIVE DESIGN's oversized power digital gear, roller power oscillation, crank power bail, and tough line roller system.
POWERDRIVE ENGINE
The body unit that realizes a highly efficient and powerful winding force is the [Power Drive Engine]. This [Power Drive Engine] is composed of two technologies, [Oversized Power Digigear] and [Roller Power Oscillation]. The drive gear has been enlarged, which is possible only with DAIWA's unique monocoque body, and the oscillation mechanism has been revamped. It realizes a clearly light and powerful winding from the initial movement.
OVERSIZED POWER DIGIGEAR
The highly durable MC Tough Digigear made of G1 duralumin has been made 10% larger in diameter and 6% thicker, making it the strongest gear ever (based on our calculation method). Even during long, high-load fights, the gears are designed to maintain a stable meshing, minimizing deflection. By significantly reducing power transmission loss, we promise smooth winding.
ROLLER POWER OSCILLATION
When fighting a large fish, where high loads continue relentlessly, the frictional resistance of the oscillating part caused by winding leads to power transmission loss. In order to reduce that friction as much as possible, the sliding part has been changed from the conventional pillar type to a two-ball bearing type oscillator. This has improved the oscillation efficiency by about 30%, realizing smooth initial response even under high loads and light, powerful winding. *Based on our own comparative test.
POWERDRIVE ROTOR
The Power Drive Rotor of the front unit has a rational spherical shape that combines rigidity and low inertia. It is composed of the Power Drive Rotor equipped with two technologies, the Crank Power Veil and the Tough Line Roller System. The unique rotor shape, which looks as if it was cut out of a sphere, is symmetrical and highly balanced with respect to the axis of rotation, ensuring high rigidity against sudden external forces. The veil and line roller mounted on this rotor have also been redesigned, enabling accurate line delivery and a smooth transition to winding operation.
*Made of aluminum.
CRANK POWER BAIL
In big games, the most important thing is to instantly reel in the line no matter when or where you are. The veil shape with an optimally inclined crank and the strengthened spring mechanism ensure that the tensioned line is guided to the line roller and prevent unexpected opening and closing. In addition, the hollow pipe structure with a thick shaft ensures high rigidity.
TOUGH LINE ROLLER SYSTEM
In order to withstand repeated high loads, the roller shaft is designed with a larger support surface and is integrated with the bail arm, eliminating the rattling that previously occurred at the joint and significantly improving durability. In addition, the newly designed PE-only line roller reduces friction with the line, achieving lighter winding. This tough new mechanism significantly improves rigidity, durability, and trouble-free performance.
*The 25SALTIGA is equipped with a line roller (non-twist buster) designed specifically for PE lines, which reduces line friction. When using monofilament lines (nylon, fluoro, etc.), line troubles are more likely to occur due to thread twisting, so we recommend replacing it with a line roller for monofilament lines (twist buster specification) that can be repaired by SLP (sold separately).
DRD
DRD is a completely new drag mechanism that can withstand the repeated running of large fish over a long period of time and prevents wear and tear and seizure at high drag ranges. The DRD washer, which is equipped with eight metal rollers on one metal plate, replaces the carbon washers used in conventional drags. It prevents the drag force from decreasing due to frictional heat and is more than five times more durable than a carbon washer (based on our comparative tests). It also contributes to a smooth start.
*Standard equipment for 18000-25000. 8000-14000 are compatible with SLP WORKS SALTIGA spool DRD14000 (to fully utilize the performance of DRD, the drag knob must be replaced with an SLP WORKS SALTIGA DRD radiation knob (sold separately)).
ATD TOUGH
The ATD operates smoothly and keeps working smoothly in response to the pull of the fish. The ATD Tough uses carbon washers to achieve high durability. It pursues smooth start and tracking, allowing you to concentrate on the fight without worrying about the drag setting.
MAGSEALED
DAIWA's unique waterproof structure creates a wall of magnetic oil in the gap between the body and rotor, blocking out seawater, dust, and other elements.
*Installed on the pinion section, line roller section, and both ends of the drive gear.
MAGSEALED LINE ROLLER
The line roller is the part that receives the water and sand that the line picks up directly. By increasing the waterproofness of the line roller under these harsh conditions, it helps maintain the initial performance such as rotation feeling and sensitivity. In addition, the amount of salt and foreign matter that gets caught is greatly reduced, and the rotation is improved, which also improves the effect of reducing line twisting.
LC-ABS SW
While the LC-ABS optimizes the spool ring shape to achieve smooth line release, the LC-ABS SW uses a two-stage taper shape on the upper side of the spool winding section toward the spool ring. This reduces friction with the line released from the deep diameter, realizing a smooth casting feel and further improving the release performance in the latter half of the cast. In particular, when using thick lines where the diameter of the winding line changes greatly during the cast, it contributes to an increase in casting distance of about 2%. It supports the desire of anglers to cast farther. *Based on our comparative tests.
Product Details
■ POWERDRIVE DESIGN Conceptual Diagram
■POWERDRIVE ENGINE
■OVERSIZED POWER DIGIGEAR
■ROLLER POWER OSCILLATION
■POWERDRIVE ROTOR
■ CRANK POWER BAIL
■TOUGH LINE ROLLER SYSTEM
■DRD
*Standard equipment for 18000-25000.
8000-14000 are compatible with SLP WORKS SALTIGA spool DRD14000 (to fully utilize the performance of DRD, the drag knob must be replaced with an SLP WORKS SALTIGA DRD radiation knob (sold separately)).
8000-14000 are compatible with SLP WORKS SALTIGA spool DRD14000 (to fully utilize the performance of DRD, the drag knob must be replaced with an SLP WORKS SALTIGA DRD radiation knob (sold separately)).
■ATD TOUGH
*Standard equipment on 8000-14000 models.
■LC-ABS SW
■ Stopperless body
The body structure has been simplified by removing the stopper. The decision to remove the stopper, which is a route for water and foreign objects to enter, not only improves waterproof performance but also minimizes the risk of sudden trouble when fishing in harsh environments or with large fish, which are required of the 25SALTIGA.
■ Manual return
In order to completely prevent the bail from flipping back when casting and to improve durability, a manual return mechanism is used that prevents the bail from flipping back when the handle is turned.
■High grip egg (compatible with L-shaped knob)
Equipped with a high-grip egg knob (exchangeable to L size) that is easy to hold and non-slip.
(*8000-P and 10000-P jigging recommended models use aluminum round knobs.)
(*8000-P and 10000-P jigging recommended models use aluminum round knobs.)
■25SALTIGA ball bearings installed in
14 places
・Pinion 2BB (SUS)
・Drive gear 2BB (Mag Sealed BB)
・Line roller 2BB (CRBB)
・Handle knob 2BB (CRBB)
・Main shaft 1BB (SUS)
・Oscillating gear 1BB (SUS)
・Oscillating slider 2BB (SUS)
・Spool 1BB (SUS)
・Spool metal 1BB (SUS)
14 places
・Pinion 2BB (SUS)
・Drive gear 2BB (Mag Sealed BB)
・Line roller 2BB (CRBB)
・Handle knob 2BB (CRBB)
・Main shaft 1BB (SUS)
・Oscillating gear 1BB (SUS)
・Oscillating slider 2BB (SUS)
・Spool 1BB (SUS)
・Spool metal 1BB (SUS)
Spool compatibility table
*1: The 25SALTIGA18000-25000 is equipped with a knob specifically for DRD. You can use the 20SALTIGA18000-20000 ATD Tough (carbon drag) spool as is, but the drag adjustment range will be narrower and it will be easier to produce high drag force, so please be careful when tightening while fishing.
*2: When using the 14000 DRD specification optional spool (sold separately), it is necessary to install a DRD radiation knob (sold separately) to maximize the performance of the DRD.
*3: The handle compatibility is as follows.
20SALTIG8000-14000 ⇔ 25SALTIGA8000-14000 Compatible
20SALTIGA18000-20000 ⇔ 25SALTIGA18000-25000 Compatible
*2: When using the 14000 DRD specification optional spool (sold separately), it is necessary to install a DRD radiation knob (sold separately) to maximize the performance of the DRD.
*3: The handle compatibility is as follows.
20SALTIG8000-14000 ⇔ 25SALTIGA8000-14000 Compatible
20SALTIGA18000-20000 ⇔ 25SALTIGA18000-25000 Compatible
Flagship after-sales service program by master craftsmen
[Service details]
① Reel counseling by a designated Meister
② Free oil check service once a year
③ Free replacement of consumable and broken parts (including repairs and overhauls)
* Period until the end of March 2031.
* A fee of 4,950 yen (tax included) will be charged. Thank you for your understanding.
* The replacement criteria for consumable and broken parts will be determined responsibly by the SLP Meister.
* Parts replaced free of charge will not be returned.
* If any costs are incurred other than the 4,950 yen fee, an estimate will be issued in advance.
* Cases in which costs are incurred: Submerged products, scratches, deformations, or damage to external parts due to dropping, etc., if you wish to replace non-consumable parts, etc.
* Please check the coupon details after issuance before using.
① Reel counseling by a designated Meister
② Free oil check service once a year
③ Free replacement of consumable and broken parts (including repairs and overhauls)
* Period until the end of March 2031.
* A fee of 4,950 yen (tax included) will be charged. Thank you for your understanding.
* The replacement criteria for consumable and broken parts will be determined responsibly by the SLP Meister.
* Parts replaced free of charge will not be returned.
* If any costs are incurred other than the 4,950 yen fee, an estimate will be issued in advance.
* Cases in which costs are incurred: Submerged products, scratches, deformations, or damage to external parts due to dropping, etc., if you wish to replace non-consumable parts, etc.
* Please check the coupon details after issuance before using.
We are now offering a special service for the 25SALTIGA.
Repairs and overhauls of the 25SALTIGA will be accepted as many times as you like within the period for a fee of 4,950 yen (tax included).
We will provide active support to all owners who purchase and register their equipment so that they can enjoy fishing for a longer period of time and in a more comfortable environment.
Repairs and overhauls of the 25SALTIGA will be accepted as many times as you like within the period for a fee of 4,950 yen (tax included).
We will provide active support to all owners who purchase and register their equipment so that they can enjoy fishing for a longer period of time and in a more comfortable environment.
[To use this program]
To use this after-sales service program, you will need to register your product in "MyDAIWA" and register as a member of SLP PLUS.
SLP PLUS is a membership service of Daiwa's after-sales service center "SLP". For those who have used SLP in the past, it is more convenient to use. For those who are using SLP for the first time, it is so that you can fully experience the professional skills that SLP has cultivated. There are no registration fees or annual fees. Please use SLP PLUS to use Daiwa fishing gear for a longer period of time and with better care.
To use this after-sales service program, you will need to register your product in "MyDAIWA" and register as a member of SLP PLUS.
SLP PLUS is a membership service of Daiwa's after-sales service center "SLP". For those who have used SLP in the past, it is more convenient to use. For those who are using SLP for the first time, it is so that you can fully experience the professional skills that SLP has cultivated. There are no registration fees or annual fees. Please use SLP PLUS to use Daiwa fishing gear for a longer period of time and with better care.
accessories
・Spool position adjustment washer
・Handle knob removal screwdriver
・Postcard
・Reel case
・Spool belt
・Handle knob removal screwdriver
・Postcard
・Reel case
・Spool belt
